| Engine | 7.5ps electric start evaporative water-cooled diesel engine |
| Hydraulic Drive Mode | The stirring shaft is driven by gear pump, multi-way hydraulic valve, relief valve and hydraulic motor |
| Heating System | The gas is supplied to the efficient direct spray stove through the valve of the oil liquefied gas tank. Adjust range: 0-300°C |
| Safety Device | The multi-way control valve has a special unloading device to prevent misoperation |
| Melting Cylinder | Significant fruit transmission, capacity 400kg (approx. 16 packs of thermal coating) |
| Shape and Structure | High strength, high temperature resistant, anti gasification stainless steel plate structure design |
| Size | 1.7 * 1.43 * 1.5m |
| Weight | 700kg |
The HW-500 employs a hydraulic drive system that includes a gear pump, multi-way hydraulic valve, relief valve, and hydraulic motor. This sophisticated setup ensures smooth and consistent mixing of the hot melt material, providing uniform quality for road marking applications.
The heating system is powered by an LPG tank, which supplies fuel to the high-efficiency direct injection furnace. This design promotes complete combustion, maximizing heat output while minimizing fuel consumption. The heating temperature can be freely adjusted between 0°C and 300°C.
The HW-500 includes a specially designed automatic overload protection device that prevents damage to hydraulic components during overloading. This safety feature ensures the longevity of the equipment and protects operators.
With a capacity of 400kg, the HW-500 is equipped to handle substantial volumes of material. Its stainless steel body and boiler iron bottom provide high strength, heat resistance, and anti-oxidation properties.
Particularly well-suited for parking lot marking projects. High combustion efficiency and long continuous operation capabilities ensure large areas are marked quickly.
Provides a reliable solution for hot-melt marking construction on community roads. Simple operation and maintenance requirements allow for quick setup.
Suitable for factories and docks. Robust construction and high-capacity design make it capable of handling heavy-duty marking tasks.
In summary, the HW-500 Hydraulic Double Cylinder Hot Melt Kettle is a powerful and reliable tool for various road marking applications. Its high combustion efficiency, long continuous operation capabilities, and user-friendly design make it an ideal choice for parking lots, residential areas, and other small-scale road surfaces.
